SIP Paging Gateway JWDT-PA3

The JWDT-PA3 is designed for seamless integration into any internal installation, making it ideal for public broadcasting applications. Featuring high-definition audio and versatile, function-rich interfaces, it supports both real-time and scheduled MP3 broadcasting. With one-touch intercom capabilities when connected to external devices, JWDT-PA3 offers effortless communication. It is the perfect choice for creating a customized, integrated broadcasting solution for campuses, shopping malls, railway stations, office buildings, and more.

Widely used in：

MARINE ENVIRONMENT

HIGHWAY SHOULDER

SUBWAY STATION

TUNNEL

UNDERGROUND FACILITY

RAILWAY PLATFORM

MINING SITE

OTHERS

KEY FEATURES

Compact & Versatile Design – Exquisitely crafted to be embedded seamlessly into other equipment for internal installation.

Adjustable Power Output – Mono channel power amplifier delivering 10W to 30W, with output power configurable according to input voltage.

Easy Audio Input – 3.5mm standard audio line-in port for plug-and-play connection.

Expandable Audio Output – Audio line-out port to connect external active speakers for extended sound coverage.

Flexible Media Support – USB 2.0 port and TF card slot for data storage or offline audio broadcasting.

Smart Network Integration – Adaptive 10/100 Mbps network port with PoE support for simplified installation and reliable connectivity.

Power Consumption (PoE)	1.85W ~ 10.8W
Standalone intercom	No Central Unit /Server Needed
Installation	Desktop stand / Wall-mounted
Linkage	with Third Party IP Camera
DC Power Supply	12V-24V 2A
Working humidity	10~95%
Audio Line-out	Expandable external active speaker interface
PoE Level	Class4
Storage Temperature	-30°C~60°C
Working Temperature	-20°C~50°C
Power Amplifier	Maximum 4Ω/30W or 8Ω/15W
Protocols	SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS, RTP/RTCP/SRTP,STUN, DHCP, IPv6, PPPoE, L2TP, OpenVPN, SNTP, FTP/TFTP, HTTP/HTTPS, TR-069

PACKAGE

We are committed to ensuring the safe arrival of your products. Each unit is placed in precision-cut, high-density foam or custom-molded cushioning, then securely packed in a heavy-duty corrugated box. Our packaging solutions undergo rigorous testing to exceed industry shipping standards, offering dependable protection against impact, vibration, and handling stresses throughout transit.

FREQUENTLY ASKED QUESTIONS

1. What is a wireless intercom gateway and what does it do?

A wireless intercom gateway is a communication convergence device that enables interconnection between traditional analog or digital two-way radios (e.g., UHF/VHF bands) and IP-based communication systems such as SIP telephony, dispatch platforms, or PA systems. Its core function is to bridge communication silos, allowing radio users to communicate with IP phones, mobile devices, dispatch consoles, and other SIP endpoints.

2. What are typical use cases?

The gateway is suitable for scenarios where traditional radio systems need to integrate with IP‑based communications, including: Property management / campuses: connecting security radios with office IP phones and control centers. Industrial manufacturing: linking workshop radios to dispatch consoles and office telephone systems. Transportation: enabling communication between field staff in tunnels, ports, or airports and central command. Emergency response: rapid deployment of interoperable communication between on-scene radios and command-center systems.

The JWDT-PA3 is a SIP-enabled public announcement system designed for industrial applications. It supports standard IP, RTP, and RTSP protocols for seamless media streaming. Equipped with multiple functions and versatile interfaces—including intercom, broadcasting, and recording—it adapts easily to a variety of application environments. Its user-friendly design allows for effortless DIY customization of paging and broadcasting solutions.

JWDT-PA3 (1)

Joiwo is more than a manufacturer—we are a professional integrator of comprehensive telecom solutions. Beyond providing high-quality terminal equipment, we design and deliver fully integrated, end-to-end communication systems tailored to your operational needs. Our expertise spans IP PBX platforms, IP servers, telephone self-diagnostics, PAGA systems, unified network management, Emergency Voice Communication Systems, and custom OEM functions for project-specific requirements, ensuring reliable, scalable, and customized solutions for every deployment.

JWDT-PA3 (4)
