Visualization Paging Console Phone JWDTB16

The JWDTB16 is a visual paging console phone designed for industrial and enterprise users. It is equipped with a flexible gooseneck microphone and supports HD hands-free calling, ensuring clear and reliable communication.

Featuring intelligent programmable DSS keys, the JWDTB16 enables one-touch calling to significantly enhance communication efficiency. Fully compatible with the standard SIP protocol, it can function as a monitoring center or a management console for office supervisors.

The device supports a wide range of functions, including internal and external calling, two-way intercom, monitoring, and broadcasting. With these capabilities, the JWDTB16 effectively improves management efficiency and strengthens emergency response performance.

Widely used in：

MARINE ENVIRONMENT

HIGHWAY SHOULDER

SUBWAY STATION

TUNNEL

UNDERGROUND FACILITY

RAILWAY PLATFORM

MINING SITE

OTHERS

KEY FEATURES

Supports up to 20 SIP lines and 3-way conferencing, with hotspot functionality

Delivers HD audio quality on both speakerphone and handset

Equipped with a movable directional external gooseneck microphone for clear voice pickup

Features a 4.3-inch main color display and two 3.5-inch side color displays for DSS keys

Built-in Bluetooth for flexible device connectivity

Wi-Fi connectivity supported via external Wi-Fi dongle

Supports up to 106 DSS keys, including 42 tri-color physical keys

Supports H.264 video codec for receiving video calls

Dual Gigabit Ethernet ports with integrated PoE support

Adjustable desktop stand with two viewing angles (40° and 50°)

Compatible with major IP PBX platforms, including Asterisk, BroadSoft, 3CX, Metaswitch, Elastix, Avaya, and more

Call Features	Audio
Call out / Answer / Reject	HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
Mute / Unmute (Microphone)	HAC handset
Call Hold / Resume	Wideband ADC/DAC 16KHz Sampling
Call Waiting	Narrowband Codec: G.711a/u, G.723.1, G.726-32K, G.729AB, AMR, iLBC
Intercom	Wideband Codec: G.722, AMR-WB, Opus
Caller ID Display	Full-duplex Acoustic Echo Canceller (AEC)
Speed Dial	Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) /Background Noise Estimation (BNE) / Noise Reduction (NR)
Anonymous Call (Hide Caller ID)	Packet Loss Concealment (PLC)
Call Forwarding (Always/Busy/No Answer)	Dynamic Adaptive Jitter Buffer up to 300ms
Call Transfer (Attended/Unattended)	DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO

Call Parking/Pick-up (Depending on server)

Redial

Do-Not-Disturb

Auto-Answering

Voice Message (On server)

3-way Conference

Hot Line

Hot desking

PACKAGE

Each telephone is shipped in durable, protective packaging designed for secure transport and storage. The packaging features impact-resistant materials and clear labeling for easy handling, with OEM and custom packaging options available.

Quality paging console for phone system setup and testing.

FREQUENTLY ASKED QUESTIONS

1.Q: What are the main advantages of this IP phone compared to a regular telephone or mobile phone?

A: The JWDTB16 is more than just a phone—it combines industrial aesthetics with intelligent communication. Compared to traditional phones, it delivers clearer and more stable internet calls, offers advanced business features (such as multi-party conferencing), and integrates seamlessly with mainstream IP telephony systems. Its elegant design also allows it to serve as a sophisticated piece of desktop art.

2.Q: Is it compatible with my existing phone system (e.g., 3CX)?

A: Yes, it is designed for broad compatibility. The JWDTB16 adheres to industry‑standard protocols and has been verified to work with major IP PBX and telephony platforms such as 3CX, Asterisk, BroadSoft, Elastix, and Zycoo. We recommend confirming with your system administrator or service provider before purchase.

3.Q: Is this phone suitable for home users, or is it only for businesses?

A: It is a versatile IP phone designed for multiple scenarios. For home offices or residential users, it offers exceptional call quality, an elegant desktop presence, and ease of use. For business users, it provides the required reliability, security, and rich business features.

The Visualization Paging Console Phone JWDTB16 is widely used in industries such as industrial manufacturing, mining and energy, tunnels and rail transit, ports and airports, public safety, and large-scale campuses. As a core dispatch terminal within communication systems, it integrates visual management, paging, zone calling, and emergency command functions, enabling centralized control and efficient coordination of various on-site terminals. In scenarios such as production dispatching, equipment management, and emergency response, the JWDTB16 significantly enhances communication efficiency and command capabilities, making it a key component in modern industrial communication and paging systems.

As both a manufacturer and solution integrator, Joiwo provides fully customized communication solutions, covering everything from terminal devices to complete end-to-end system deployment. Leveraging strong in-house R&D and manufacturing capabilities, we are able to tailor hardware, software, and system architecture to meet the specific requirements of diverse industries and projects.

Our solutions support a wide range of advanced communication technologies, including IP PBX systems, IP-based servers, intelligent phone self-diagnostics, Public Address and General Alarm (PAGA) systems, unified network management platforms, and Emergency Voice Communication Systems (EVCS). In addition, Joiwo offers project-oriented OEM and ODM customization services, enabling seamless integration with customer platforms, protocols, and operational environments.

With a focus on reliability, scalability, and rapid deployment, Joiwo helps customers build efficient, secure, and future-proof communication infrastructures for mission-critical and industrial applications.
